Product Description

SCR(SGR, SEU) type double-spiral silicon carbide heating elements are cut so as to place both electrical terminations on the same end of the element.They are supplied with the terminal assembly attached. SGR (SCR) type Torch Furnace silicon carbide design or dimensions preclude wiring from both sides of the furnace. This type is ideal for blind holes and the operating temperature can be up to 1500 deg C.

it is also widely used in various high temperature electric furnaces and other electric heating debices, such as in the industrial of magnet, ceramics, powder metallurgy, glass, metallurgy and michinery etc.

Features:

1, High temperature resistance, resistance to oxidation and corrosion

2, Fast heating, long life, small deformation at high temperature, easy to install and maintain

3, With automatic electronic control systems, precision constant temperature can be obtained, curve temperature control can be obtained too according to the needs of production

To Order SCR (SGR, SEU) Type Silicon Carbide Heating Rod, please provide the following information:

Type: SCR

Outer diameter (OD): mm

Hot zone length (HZ): mm

Cold end length (CZ): mm

Overall length (OL): mm

Example:

SCR,OD=31.7mm,HZ=305mm,CZ=241mm,OL=546mm,Resistance 4.46 ohms

Specify as: SCR,31.7/305/546/4.46 ohms
